CGreffe3DTask Class Reference
Detailed Description
CGreffe3DTask.Public Member Functions | |
| virtual unsigned | GetTaskResID () const |
| Return the resource identifier for the title of the task. | |
| virtual unsigned | GetHelpResID () |
| Return the resource identifier for the help message associated with the current step of the task. | |
| virtual DWORD | GetMask () |
| Return a mask used to filter the objects that the user will be able to designate on the main view. | |
| virtual void | DrawFeedBack (CDC *) |
| Called by the main view to draw the visual feedback associated with the current step of the task. | |
| virtual void | CreateObject3D () |
| Called by the task to create and initialise the resulting object, if any, and insert it in the universe. | |
Member Function Documentation
| virtual unsigned GetTaskResID | ( | ) | const [inline, virtual] |
Return the resource identifier for the title of the task.
Both GetHelpResID() and GetTaskResID() are used to populate the Status Bar with a message describing the current stage of the task.
Reimplemented from CTask.
| unsigned GetHelpResID | ( | ) | [virtual] |
Return the resource identifier for the help message associated with the current step of the task.
Both GetHelpResID() and GetTaskResID() are used to populate the Status Bar with a message describing the current stage of the task.
Reimplemented from CTask.
| DWORD GetMask | ( | ) | [virtual] |
Return a mask used to filter the objects that the user will be able to designate on the main view.
The filter is a bitwise combination of objects identifiers (see TObject3DClass and others). See CObject3D::MaskObject and CObject3D::isA for description of the filter mechanism.
Reimplemented from CTask.
| void DrawFeedBack | ( | CDC * | ) | [virtual] |
Called by the main view to draw the visual feedback associated with the current step of the task.
Reimplemented from CTask.
| void CreateObject3D | ( | ) | [virtual] |
Called by the task to create and initialise the resulting object, if any, and insert it in the universe.
Reimplemented from CTask.
